Request a quote for pricing
Priced by quantity and lead time.
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Switch Function
- On-Mom
- Parça Durumu
- Active
- Orientation
- Straight
- Genişlik
- 44.4mm
- Montaj Tipi
- Chassis Mount
- Fabrika Tedarik Süresi
- 20 Weeks
- Max Current Rating
- 15A
- Actuator Type
- Lever, Roller
- Ambalaj
- Bulk
- Reach Svhc
- Unknown
- Yükseklik
- 91.4mm
- Akım Değeri
- 15A
- Housing Material
- Zinc
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Seri
- E6
- Number Of Poles
- 1
- Onay Kuruluşu
- CSA, UL
- Overtravel
- 0.219 (5.6mm)
- Contact Currentdcmax
- 0.5A
- Kurşunsuz Kodu
- yes
- Voltage Rated Dc
- 125V
- Uzunluk
- 25.4mm
- ECCN Kodu
- EAR99
- Montaj
- Chassis Mount, Screw
- HTS Kodu
- 8536.50.70.00
- Pretravel
- 0.188 (4.8mm)
- Terminal
- Conduit
- Ingress Protection
- IP40
- Differential Travel
- 0.006 (0.15mm)
- Çalışma Sıcaklığı
- -32°C~71°C
- Circuit
- SPDT
- Release Force
- 170gf
- Pretravelmax
- 4.78 mm
- RoHS Durumu
- RoHS Compliant
- Operating Force
- 283 ~ 510gf
- Pozisyon Sayısı
- 2
- Terminal Stili
- Screw Terminal
- Max Voltage Rating Ac
- 600V
- Yayın Yılı
- 2001
- Max Voltage Rating Dc
- 250V
