Volume pricing
- 1+ pcs$173.74
- 10+ pcs$163.90
- 100+ pcs$154.62
- 500+ pcs$145.87
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Circuit
- SPDT
- Release Force
- 113gf
- Çalışma Sıcaklığı
- -32°C~71°C
- Ratings
- IP54, IP66, Water Resistant
- Terminal
- Conduit
- Differential Travel
- 0.002 (0.05mm)
- Ingress Protection
- IP54 - Dust Protected, Water Resistant
- Pretravel
- 0.078 (2.0mm)
- Montaj
- Chassis Mount, Screw
- ECCN Kodu
- EAR99
- HTS Kodu
- 8536.50.70.00
- Body Breadth
- 25.4 mm
- Voltage Rated Dc
- 125V
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Body Length Or Diameter
- 77.22mm
- Operating Position
- 2.232 (56.7mm)
- Current Rating Amps
- 15A AC 500mA DC
- Voltage Rated Ac
- 125V
- Max Voltage Rating Dc
- 250V
- Contact Dc Max Rating R Load
- .5A@125VDC
- Yayın Yılı
- 2005
- Contact Ac Max Rating R Load
- 15A@480VAC
- Operating Force
- 255 ~ 680gf
- Terminal Stili
- Screw Terminal
- RoHS Durumu
- RoHS Compliant
- Pretravelmax
- 1.98 mm
- Özellikler
- Actuator Seal Boot
- Akım Değeri
- 15A
- Housing Material
- Zinc
- Contact Voltageacmax
- 480V
- Fabrika Tedarik Süresi
- 20 Weeks
- Max Current Rating
- 15A
- Ambalaj
- Bulk
- Actuator Type
- Roller Plunger
- Body Height
- 44.45mm
- Montaj Tipi
- Chassis Mount
- Switch Function
- On-Mom
- Parça Durumu
- Active
- Orientation
- Straight
- Kurşunsuz Kodu
- yes
