Volume pricing
- 1+ pcs$129.71
- 10+ pcs$122.37
- 100+ pcs$115.45
- 500+ pcs$108.91
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Ingress Protection
- IP54 - Dust Protected, Water Resistant
- Differential Travel
- 0.002 (0.05mm)
- Voltage Rated Dc
- 125V
- Uzunluk
- 77.2mm
- Max Voltage Rating Dc
- 250V
- Voltage Rated Ac
- 125V
- Özellikler
- Actuator Seal Boot
- Operating Force
- 680gf
- Terminal Stili
- Screw Terminal
- Contact Current Rating
- 15A
- Montaj Tipi
- Chassis Mount
- Max Current Rating
- 15A
- Ambalaj
- Bulk
- Akım Değeri
- 15A
- Switch Function
- On-Mom
- Parça Durumu
- Active
- Genişlik
- 44.4mm
- Orientation
- Straight
- Actuator Travel
- 7.54 mm
- Kurşunsuz Kodu
- yes
- Onay Kuruluşu
- CSA, UL
- Terminal
- Conduit
- Ratings
- IP54, IP66, Water Resistant
- Çalışma Sıcaklığı
- -32°C~71°C
- Circuit
- SPDT
- Release Force
- 113gf
- Kılıf / Paket
- 600
- Montaj
- Chassis Mount, Screw
- ECCN Kodu
- EAR99
- HTS Kodu
- 8536.50.70.00
- Pretravel
- 0.078 (2.0mm)
- Sealing
- CORROSION PROOF; IP54
- Current Rating Amps
- 15A AC 500mA DC
- Operating Position
- 2.232 (56.7mm)
- Depth
- 77.2mm
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- RoHS Durumu
- RoHS Compliant
- Pozisyon Sayısı
- 2
- Max Voltage Rating Ac
- 600V
- Yayın Yılı
- 2001
