Volume pricing
- 1+ pcs$219.18
- 10+ pcs$206.77
- 100+ pcs$195.07
- 500+ pcs$184.03
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Pretravelmax
- 4.78 mm
- RoHS Durumu
- RoHS Compliant
- Özellikler
- Actuator Seal Boot
- Yayın Yılı
- 2005
- Operating Force
- 283 ~ 567gf
- Terminal Stili
- Screw Terminal
- Pozisyon Sayısı
- 2
- Voltage Rated Ac
- 125V
- Current Rating Amps
- 15A AC 500mA DC
- Max Voltage Rating Dc
- 250V
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Depth
- 44.4mm
- Montaj
- Chassis Mount, Screw
- ECCN Kodu
- EAR99
- Uzunluk
- 25.4mm
- HTS Kodu
- 8536.50.70.00
- Voltage Rated Dc
- 125V
- Pretravel
- 0.188 (4.8mm)
- Ratings
- IP54, IP66, Water Resistant
- Terminal
- Conduit
- Ingress Protection
- IP54 - Dust Protected, Water Resistant
- Differential Travel
- 0.006 (0.15mm)
- Release Force
- 170gf
- Circuit
- SPDT
- Çalışma Sıcaklığı
- -32°C~71°C
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Seri
- E6
- Number Of Poles
- 1
- Onay Kuruluşu
- CSA, UL
- Contact Currentdcmax
- 0.5A
- Overtravel
- 0.219 (5.6mm)
- Kurşunsuz Kodu
- yes
- Switch Function
- On-Mom
- Parça Durumu
- Active
- Orientation
- Straight
- Genişlik
- 77.2mm
- Fabrika Tedarik Süresi
- 20 Weeks
- Max Current Rating
- 15A
- Body Height
- 78.58mm
- Actuator Type
- Manual Palm Button
