Volume pricing
- 1+ pcs$146.23
- 10+ pcs$137.95
- 100+ pcs$130.15
- 500+ pcs$122.78
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Contact Ac Max Rating R Load
- 15A@480VAC
- Operating Force
- 397 ~ 992gf
- Terminal Stili
- Screw Terminal
- Yayın Yılı
- 2012
- Contact Dc Max Rating R Load
- 1A@125VDC
- Özellikler
- Actuator Seal Boot
- Pretravelmax
- 1.98 mm
- RoHS Durumu
- RoHS Compliant
- Contact Currentacmax
- 15A
- Operating Position
- 1.720 (43.7mm)
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Body Length Or Diameter
- 69.6mm
- Throw Configuration
- SPDT
- Max Voltage Rating Dc
- 250V
- Current Rating Amps
- 15A AC 1A DC
- Voltage Rated Ac
- 125V
- Pretravel
- 0.078 (2.0mm)
- Voltage Rated Dc
- 125V
- ECCN Kodu
- EAR99
- Montaj
- Chassis Mount, Screw
- Body Breadth
- 25.4 mm
- HTS Kodu
- 8536.50.70.00
- Çalışma Sıcaklığı
- -32°C~71°C
- Circuit
- SPDT (DB/DM)
- Release Force
- 113gf
- Terminal
- Conduit
- Differential Travel
- 0.004 (0.1mm)
- Ingress Protection
- IP66 - Dust Tight, Water Resistant
- Ratings
- Dust Tight, IP66, Water Resistant
- Seri
- E6
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Kurşunsuz Kodu
- yes
- Actuator Travel
- 7.54 mm
- Overtravel
- 0.219 (5.6mm)
- Contact Currentdcmax
- 1A
- Switch Function
- On-Mom
- Parça Durumu
- Active
- Orientation
- Straight
- Contact Voltageacmax
- 480V
- Housing Material
- Zinc
