Specifications
- Terminal
- Screw
- Yayın Yılı
- 2013
- Parça Durumu
- Active
- Çalışma Sıcaklığı
- -55°C~85°C
- Fabrika Tedarik Süresi
- 25 Weeks
- Switch Function
- On-Mom
- Mechanical Life
- 20,000,000 Cycles
- Circuit
- SPDT
- Terminal Stili
- Screw Terminal
- Actuator Type
- Lever, Roller
- Voltage Rated Ac
- 125V
- Operating Force
- 28 ~ 127gf
- Pretravelmax
- 11.91 mm
- Montaj
- Chassis Mount, Panel, Screw
- Current Rating Amps
- 15A AC 500mA DC
- Akım Değeri
- 15A
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Pretravel
- 0.470 (11.9mm)
- Seri
- BZ
- Actuator Travel
- 15.87 mm
- Depth
- 17.45mm
- ECCN Kodu
- EAR99
- RoHS Durumu
- RoHS Compliant
- Differential Travel
- 0.150 (3.8mm)
- REACH Uyumluluk Kodu
- unknown
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Overtravel
- 0.156 (3.96mm)
- Body Length Or Diameter
- 49.28mm
- Housing Material
- Phenolic
- Sealing
- CORROSION PROOF
- Release Force
- 21gf
- Actuator Length
- 4.822m
- HTS Kodu
- 8536.50.70.00
- Ambalaj
- Bulk
- Orientation
- Straight
- Operating Position
- 1.188 (30.2mm)
- Weight
- 345g
- Voltage Rated Dc
- 125V
- Body Height
- 29.21mm
- Montaj Tipi
- Chassis Mount
