Specifications
- Terminal
- Screw
- Contact Current Rating
- 15A
- Yayın Yılı
- 2013
- Material
- Plastic
- Çalışma Sıcaklığı
- -55°C~85°C
- Fabrika Tedarik Süresi
- 10 Weeks
- Switch Function
- On-Mom
- Mechanical Life
- 20,000,000 Cycles
- Parça Durumu
- Active
- Actuator Type
- Roller Plunger
- Voltage Rated Ac
- 125V
- Circuit
- SPDT
- Terminal Stili
- Screw Terminal
- Akım Değeri
- 15A
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Operating Force
- 624 ~ 794gf
- Montaj
- Panel, Screw
- Pretravelmax
- 0.76 mm
- Current Rating Amps
- 15A AC 500mA DC
- Pretravel
- 0.030 (0.8mm)
- Seri
- BZ
- Depth
- 17.45mm
- Max Current Rating
- 16A
- Max Voltage Rating Ac
- 480V
- Max Voltage Rating Dc
- 250V
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Contact Ac Max Rating R Load
- 15A@480VAC
- Overtravel
- 0.141 (3.6mm)
- Contact Currentdcmax
- 0.5A
- Differential Travel
- 0.005 (0.13mm)
- RoHS Durumu
- RoHS Compliant
- ECCN Kodu
- EAR99
- Kurşunsuz Kodu
- yes
- Reach Svhc
- No SVHC
- HTS Kodu
- 8536.50.70.00
- Ambalaj
- Bulk
- Orientation
- Straight
- Housing Material
- Phenolic
- Release Force
- 113gf
- Contact Materials
- Silver
