Specifications
- Orientation
- Straight
- JESD-609 Kodu
- e3
- Ambalaj
- Bulk
- Housing Material
- Phenolic
- Release Force
- 113gf
- Contact Materials
- Silver
- Weight
- 3.401kg
- Operating Position
- 1.313 (33.4mm)
- Actuator Material
- Stainless Steel
- Body Height
- 27.69mm
- Montaj Tipi
- Panel Mount
- Uzunluk
- 49.28mm
- Depth
- 17.45mm
- Max Current Rating
- 5A
- Pretravel
- 0.030 (0.8mm)
- Seri
- BZ
- Max Voltage Rating Ac
- 250V
- Contact Ac Max Rating R Load
- 5A@250VAC
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Terminal Kaplaması
- Matte Tin (Sn)
- Overtravel
- 0.141 (3.6mm)
- Reach Svhc
- Unknown
- Kurşunsuz Kodu
- yes
- ECCN Kodu
- EAR99
- RoHS Durumu
- RoHS Compliant
- Differential Travel
- 0.004 (0.1mm)
- Actuator Type
- Roller Plunger
- Voltage Rated Ac
- 250V
- Contact Currentacmax
- 5A
- Circuit
- SPDT
- Terminal Stili
- Screw Terminal
- Akım Değeri
- 5A
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Pretravelmax
- 0.77 mm
- Montaj
- Panel, Screw
- Operating Force
- 454 ~ 737gf
- Current Rating Amps
- 5A AC
- Terminal
- Screw
- Yayın Yılı
- 2004
- Fabrika Tedarik Süresi
- 9 Weeks
