Specifications
- Contact Materials
- Silver
- Weight
- 3.401kg
- Operating Position
- 0.625 (15.9mm)
- Voltage Rated Dc
- 125V
- Body Height
- 26.67mm
- Montaj Tipi
- Chassis Mount
- Contact Dc Max Rating R Load
- 1A@125VDC
- Uzunluk
- 49.28mm
- HTS Kodu
- 8536.50.70.00
- Orientation
- Straight
- Ambalaj
- Bulk
- JESD-609 Kodu
- e3
- Housing Material
- Phenolic
- Release Force
- 113gf
- Contact Ac Max Rating R Load
- 15A@480VAC
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Terminal Kaplaması
- Matte Tin (Sn)
- Overtravel
- 0.005 (0.13mm)
- Contact Currentdcmax
- 1A
- Reach Svhc
- No SVHC
- Kurşunsuz Kodu
- yes
- ECCN Kodu
- EAR99
- RoHS Durumu
- RoHS Compliant
- Differential Travel
- 0.005 (0.13mm)
- Actuator Travel
- 0.13 mm
- Max Current Rating
- 15A
- Depth
- 17.45mm
- Seri
- BZ
- Max Voltage Rating Ac
- 480V
- Max Voltage Rating Dc
- 250V
- Akım Değeri
- 1A
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Pretravelmax
- 0.13 mm
- Montaj
- Chassis Mount, Panel, Screw
- Operating Force
- 454 ~ 794gf
- Current Rating Amps
- 15A AC 1A DC
- Actuator Type
- Round (Pin Plunger)
- Voltage Rated Ac
- 125V
- Circuit
- SPDT
- Terminal Stili
- Screw Terminal
