Specifications
- Yayın Yılı
- 2015
- Terminal
- Screw
- Parça Durumu
- Active
- Mechanical Life
- 20,000,000 Cycles
- Material
- Plastic
- Fabrika Tedarik Süresi
- 9 Weeks
- Actuator Type
- Lever, Straight
- Current Rating Amps
- 15A AC 500mA DC
- Max Voltage Rating Ac
- 480V
- Seri
- BZ
- Depth
- 17.45mm
- Actuator Travel
- 3.58 mm
- Max Current Rating
- 16A
- Kurşunsuz Kodu
- yes
- ECCN Kodu
- EAR99
- RoHS Durumu
- RoHS Compliant
- Reach Svhc
- No SVHC
- Overtravel
- 0.141 (3.6mm)
- Contact Ac Max Rating R Load
- 15A@480VAC
- Housing Material
- Phenolic
- Ambalaj
- Bulk
- JESD-609 Kodu
- e3
- Orientation
- Straight
- Actuator Length
- 3.175m
- Uzunluk
- 49.28mm
- Voltage Rated Dc
- 125V
- Contact Current Rating
- 15A
- Switch Function
- On-Mom
- Çalışma Sıcaklığı
- -55°C~85°C
- Terminal Stili
- Screw Terminal
- Circuit
- SPDT
- Voltage Rated Ac
- 125V
- Operating Force
- 170gf
- Pretravelmax
- 3.58 mm
- Montaj
- Chassis Mount, Panel, Screw
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Akım Değeri
- 15A
- Max Voltage Rating Dc
- 250V
- Differential Travel
- 0.025 (0.6mm)
- Contact Currentdcmax
- 0.5A
