Honeywell Sensing and Productivity Solutions
BZ-2RW8435-A2
Snap Action Switches
In StockRoHS: Compliant
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Switch Function
- On-Mom
- Mechanical Life
- 20,000,000 Cycles
- Fabrika Tedarik Süresi
- 25 Weeks
- Çalışma Sıcaklığı
- -55°C~85°C
- Material
- Plastic
- Parça Durumu
- Active
- Yayın Yılı
- 2001
- Terminal
- Screw
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Akım Değeri
- 10A
- Current Rating Amps
- 10A AC 500mA DC
- Pretravelmax
- 8.33 mm
- Montaj
- Chassis Mount, Panel, Screw
- Operating Force
- 14gf
- Voltage Rated Ac
- 125V
- Actuator Type
- Lever, Straight
- Terminal Stili
- Screw Terminal
- Circuit
- SPDT
- Overtravel
- 0.219 (5.6mm)
- Onay Kuruluşu
- CE, CSA
- Contact Ac Max Rating R Load
- 10A@480VAC
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Terminal Kaplaması
- Matte Tin (Sn)
- Differential Travel
- 0.050 (1.3mm)
- Kurşunsuz Kodu
- yes
- ECCN Kodu
- EAR99
- RoHS Durumu
- RoHS Compliant
- Contact Currentdcmax
- 0.5A
- Max Current Rating
- 10A
- Depth
- 17.45mm
- Actuator Travel
- 13.89 mm
- Seri
- BZ
- Pretravel
- 0.328 (8.3mm)
- Max Voltage Rating Dc
- 250V
- Max Voltage Rating Ac
- 480V
- Contact Materials
- Silver
- Voltage Rated Dc
- 125V
- Body Height
- 29.21mm
- Montaj Tipi
- Chassis Mount
- Contact Dc Max Rating R Load
- .5A@125VDC
