Honeywell Sensing and Productivity Solutions
BZ-2RW843589-P4
Snap Action Switches
In StockRoHS: Compliant
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Body Length Or Diameter
- 49.28mm
- Housing Material
- Phenolic
- Release Force
- 7.087gf
- HTS Kodu
- 8536.50.70.00
- Ambalaj
- Bulk
- Orientation
- Straight
- Operating Position
- 0.798 (20.3mm)
- Weight
- 3.401kg
- Contact Dc Max Rating R Load
- .5A@125VDC
- Montaj Tipi
- Chassis Mount
- Body Height
- 26.67mm
- Voltage Rated Dc
- 125V
- Contact Materials
- Silver
- Max Voltage Rating Ac
- 480V
- Max Voltage Rating Dc
- 250V
- Seri
- BZ
- Actuator Travel
- 0.89 mm
- Contact Currentdcmax
- 0.5A
- Differential Travel
- 0.016 (0.4mm)
- RoHS Durumu
- RoHS Compliant
- ECCN Kodu
- EAR99
- Kurşunsuz Kodu
- yes
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Contact Ac Max Rating R Load
- 10A@480VAC
- Overtravel
- 0.035 (0.9mm)
- Circuit
- SPDT
- Terminal Stili
- Screw Terminal
- Actuator Type
- Lever, Formed
- Voltage Rated Ac
- 125V
- Operating Force
- 35gf
- Montaj
- Chassis Mount, Screw
- Current Rating Amps
- 10A AC 500mA DC
- Akım Değeri
- 10A
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Body Breadth
- 17.45 mm
- Terminal
- Screw
- Yayın Yılı
- 1999
- Parça Durumu
- Active
- Çalışma Sıcaklığı
- -55°C~85°C
- Material
- Plastic
