Specifications
- Terminal
- Screw
- Yayın Yılı
- 1999
- Contact Voltageacmax
- 250V
- Body Breadth
- 17.45 mm
- Fabrika Tedarik Süresi
- 5 Weeks
- Material
- Plastic
- Mechanical Life
- 20,000,000 Cycles
- Parça Durumu
- Active
- Actuator Type
- Lever, Straight
- Current Rating Amps
- 15A AC 500mA DC
- Depth
- 17.5mm
- Actuator Travel
- 5.56 mm
- Max Current Rating
- 15A
- Seri
- BZ
- Contact Ac Max Rating R Load
- 15A@250VAC
- Overtravel
- 0.219 (5.6mm)
- Reach Svhc
- Unknown
- Kurşunsuz Kodu
- yes
- ECCN Kodu
- EAR99
- RoHS Durumu
- RoHS Compliant
- Actuator Length
- 635mm
- Orientation
- Straight
- Ambalaj
- Bulk
- Housing Material
- Phenolic
- Sealing
- SPLASH PROOF
- Voltage Rated Dc
- 125V
- Uzunluk
- 49.3mm
- Contact Current Rating
- 15A
- Çalışma Sıcaklığı
- -55°C~85°C
- Switch Function
- On-Mom
- Voltage Rated Ac
- 125V
- Circuit
- SPDT
- Terminal Stili
- Screw Terminal
- Akım Değeri
- 15A
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Ratings
- Dust Tight, IP64, Water Resistant
- Montaj
- Chassis Mount, Screw
- Operating Force
- 71gf
- Onay Kuruluşu
- CSA, UL
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
