Specifications
- Yayın Yılı
- 2013
- Terminal
- Screw
- Parça Durumu
- Active
- Mechanical Life
- 20,000,000 Cycles
- Switch Function
- On-Mom
- Material
- Plastic
- Çalışma Sıcaklığı
- -55°C~85°C
- Fabrika Tedarik Süresi
- 25 Weeks
- Terminal Stili
- Solder Lug
- Circuit
- SPDT
- Voltage Rated Ac
- 125V
- Actuator Type
- Overtravel Plunger
- Current Rating Amps
- 15A AC 500mA DC
- Operating Force
- 255 ~ 368gf
- Montaj
- Chassis Mount, Screw
- Pretravelmax
- 0.38 mm
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Akım Değeri
- 15A
- Özellikler
- Steel Plunger
- Max Voltage Rating Dc
- 250V
- Max Voltage Rating Ac
- 480V
- Pretravel
- 0.015 (0.4mm)
- Seri
- BZ
- Depth
- 17.45mm
- Max Current Rating
- 16A
- Differential Travel
- 0.002 (0.05mm)
- RoHS Durumu
- RoHS Compliant
- Kurşunsuz Kodu
- yes
- REACH Uyumluluk Kodu
- unknown
- Contact Currentdcmax
- 0.5A
- Overtravel
- 0.060 (1.5mm)
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Contact Ac Max Rating R Load
- 15A@480VAC
- Release Force
- 113gf
- Housing Material
- Phenolic
- Ambalaj
- Bulk
- Orientation
- Straight
- Contact Dc Max Rating R Load
- .5A@125VDC
- Uzunluk
- 49.28mm
- Voltage Rated Dc
- 125V
