Specifications
- Operating Position
- 1.703 (43.3mm)
- Weight
- 39g
- Uzunluk
- 49.28mm
- Contact Dc Max Rating R Load
- .5A@125VDC
- Montaj Tipi
- Panel Mount
- Body Height
- 23.62mm
- Voltage Rated Dc
- 125V
- Contact Materials
- Silver
- Housing Material
- Phenolic
- Release Force
- 113gf
- HTS Kodu
- 8536.50.70.00
- Ambalaj
- Bulk
- Orientation
- Straight
- Contact Currentdcmax
- 0.5A
- RoHS Durumu
- RoHS Compliant
- ECCN Kodu
- EAR99
- Kurşunsuz Kodu
- yes
- Differential Travel
- 0.002 (0.05mm)
- Reach Svhc
- Unknown
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Contact Ac Max Rating R Load
- 15A@480VAC
- Overtravel
- 0.141 (3.6mm)
- Max Voltage Rating Ac
- 250V
- Pretravel
- 0.015 (0.4mm)
- Seri
- BZ
- Max Current Rating
- 15A
- Depth
- 17.45mm
- Actuator Travel
- 3.96 mm
- Operating Force
- 255 ~ 368gf
- Pretravelmax
- 0.38 mm
- Montaj
- Panel, Screw
- Current Rating Amps
- 15A AC 500mA DC
- Akım Değeri
- 15A
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Circuit
- SPDT
- Terminal Stili
- Screw Terminal
- Actuator Type
- Overtravel Plunger
- Voltage Rated Ac
- 125V
- Parça Durumu
- Active
- Çalışma Sıcaklığı
- -55°C~85°C
