Volume pricing
- 1+ pcs$16.57
- 10+ pcs$15.63
- 100+ pcs$14.74
- 500+ pcs$13.91
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Terminal Stili
- Screw Terminal
- Circuit
- SPDT
- Voltage Rated Ac
- 125V
- Actuator Type
- Overtravel Plunger
- Current Rating Amps
- 15A AC 500mA DC
- Pretravelmax
- 0.38 mm
- Montaj
- Panel, Screw
- Operating Force
- 255 ~ 368gf
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Akım Değeri
- 15A
- Body Breadth
- 17.44 mm
- Yayın Yılı
- 2001
- Contact Current Rating
- 15A
- Terminal
- Screw
- Parça Durumu
- Active
- Switch Function
- On-Mom
- Mechanical Life
- 20,000,000 Cycles
- Fabrika Tedarik Süresi
- 9 Weeks
- Çalışma Sıcaklığı
- -55°C~85°C
- Material
- Plastic
- Release Force
- 113gf
- Housing Material
- Phenolic
- Orientation
- Straight
- Ambalaj
- Bulk
- HTS Kodu
- 8536.50.90.40
- Montaj Tipi
- Panel Mount
- Body Height
- 26.42mm
- Voltage Rated Dc
- 125V
- Contact Dc Max Rating R Load
- 15A@125VDC
- Uzunluk
- 49.28mm
- Weight
- 39g
- Operating Position
- 1.500 (38.1mm)
- Actuator Material
- Steel
- Contact Materials
- Silver
- Max Voltage Rating Dc
- 250V
- Max Voltage Rating Ac
- 600V
- Max Current Rating
- 16A
- Depth
- 17.45mm
- Pretravel
- 0.015 (0.4mm)
- Seri
- BZ
