Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Orientation
- Straight
- Ambalaj
- Bulk
- JESD-609 Kodu
- e3
- HTS Kodu
- 8536.50.70.00
- Release Force
- 113gf
- Housing Material
- Phenolic
- Contact Materials
- Silver
- Voltage Rated Dc
- 125V
- Montaj Tipi
- Chassis Mount
- Body Height
- 23.62mm
- Contact Dc Max Rating R Load
- .5A@125VDC
- Uzunluk
- 49.28mm
- Weight
- 3.401kg
- Operating Position
- 1.500 (38.1mm)
- Actuator Material
- Steel
- Max Current Rating
- 16A
- Depth
- 17.45mm
- Pretravel
- 0.015 (0.4mm)
- Seri
- BZ
- Max Voltage Rating Dc
- 250V
- Max Voltage Rating Ac
- 480V
- Overtravel
- 0.219 (5.6mm)
- Contact Ac Max Rating R Load
- 15A@480VAC
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Terminal Kaplaması
- Matte Tin (Sn)
- ECCN Kodu
- EAR99
- Kurşunsuz Kodu
- yes
- RoHS Durumu
- RoHS Compliant
- Differential Travel
- 0.002 (0.05mm)
- Contact Currentdcmax
- 0.5A
- Voltage Rated Ac
- 125V
- Actuator Type
- Overtravel Plunger
- Terminal Stili
- Screw Terminal
- Circuit
- SPDT
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Akım Değeri
- 15A
- Current Rating Amps
- 15A AC 500mA DC
- Pretravelmax
- 0.38 mm
- Montaj
- Chassis Mount, Screw
- Operating Force
- 255 ~ 368gf
