Specifications
- Parça Durumu
- Active
- Mechanical Life
- 20,000,000 Cycles
- Switch Function
- On-Mom
- Fabrika Tedarik Süresi
- 10 Weeks
- Material
- Plastic
- Çalışma Sıcaklığı
- -55°C~85°C
- Yayın Yılı
- 2002
- Contact Current Rating
- 15A
- Terminal
- Solder
- Current Rating Amps
- 15A AC 500mA DC
- Montaj
- Chassis Mount, Screw
- Operating Force
- 141gf
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Akım Değeri
- 15A
- Terminal Stili
- Solder Lug
- Circuit
- SPDT
- Voltage Rated Ac
- 125V
- Actuator Type
- Lever, Roller
- Reach Svhc
- No SVHC
- Differential Travel
- 0.050 (1.3mm)
- RoHS Durumu
- RoHS Compliant
- ECCN Kodu
- EAR99
- Kurşunsuz Kodu
- yes
- Contact Currentdcmax
- 0.5A
- Overtravel
- 0.060 (1.5mm)
- Contact Ac Max Rating R Load
- 15A@480VAC
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Max Voltage Rating Dc
- 250V
- Max Voltage Rating Ac
- 480V
- Depth
- 17.45mm
- Max Current Rating
- 16A
- Seri
- BZ
- Voltage Rated Dc
- 125V
- Body Height
- 21.08mm
- Montaj Tipi
- Chassis Mount
- Contact Dc Max Rating R Load
- .5A@125VDC
- Uzunluk
- 62.66mm
- Weight
- 286g
- Operating Position
- 1.125 (28.6mm)
- Actuator Material
- Stainless Steel
