Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Orientation
- Straight
- JESD-609 Kodu
- e3
- Ambalaj
- Bulk
- Housing Material
- Phenolic
- Voltage Rated Dc
- 125V
- Uzunluk
- 49.28mm
- Actuator Material
- Steel
- Depth
- 17.45mm
- Max Current Rating
- 16A
- Seri
- BZ
- Max Voltage Rating Ac
- 480V
- Overtravel
- 0.060 (1.5mm)
- Contact Ac Max Rating R Load
- 15A@480VAC
- RoHS Durumu
- RoHS Compliant
- ECCN Kodu
- EAR99
- Kurşunsuz Kodu
- yes
- Actuator Type
- Round (Pin Plunger)
- Özellikler
- Steel Plunger
- Current Rating Amps
- 15A AC 500mA DC
- Yayın Yılı
- 1999
- Terminal
- Screw
- Mechanical Life
- 20,000,000 Cycles
- Fabrika Tedarik Süresi
- 9 Weeks
- Material
- Plastic
- Parça Durumu
- Active
- HTS Kodu
- 8536.50.70.00
- Release Force
- 113gf
- Contact Materials
- Silver
- Montaj Tipi
- Chassis Mount
- Body Height
- 23.62mm
- Contact Dc Max Rating R Load
- .5A@125VDC
- Weight
- 3.401kg
- Operating Position
- 0.835 (21.2mm)
- Pretravel
- 0.015 (0.4mm)
- Max Voltage Rating Dc
- 250V
- Terminal Kaplaması
- Matte Tin (Sn)
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Differential Travel
- 0.002 (0.05mm)
- Contact Currentdcmax
- 0.5A
- Voltage Rated Ac
- 125V
