Specifications
- Contact Materials
- Silver
- Voltage Rated Dc
- 125V
- Body Height
- 21.34mm
- Montaj Tipi
- Chassis Mount
- Contact Dc Max Rating R Load
- .5A@125VDC
- Weight
- 286g
- Operating Position
- 0.625 (15.9mm)
- Orientation
- Straight
- Ambalaj
- Bulk
- HTS Kodu
- 8536.50.70.00
- Release Force
- 113gf
- Body Length Or Diameter
- 49.28mm
- Housing Material
- Phenolic
- Overtravel
- 0.005 (0.13mm)
- Contact Ac Max Rating R Load
- 16A@250VAC
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Reach Svhc
- No SVHC
- Kurşunsuz Kodu
- yes
- ECCN Kodu
- EAR99
- RoHS Durumu
- RoHS Compliant
- Differential Travel
- 0.002 (0.05mm)
- Contact Currentdcmax
- 0.5A
- Actuator Travel
- 0.51 mm
- Pretravel
- 0.015 (0.4mm)
- Seri
- BZ
- Max Voltage Rating Dc
- 250V
- Max Voltage Rating Ac
- 480V
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Akım Değeri
- 15A
- Current Rating Amps
- 15A AC 500mA DC
- Pretravelmax
- 0.38 mm
- Montaj
- Chassis Mount, Screw
- Operating Force
- 255 ~ 368gf
- Voltage Rated Ac
- 125V
- Contact Currentacmax
- 16A
- Actuator Type
- Round (Pin Plunger)
- Terminal Stili
- Screw Terminal
- Circuit
- SPDT
- Switch Function
- On-Mom
- Mechanical Life
- 20,000,000 Cycles
