Volume pricing
- 1+ pcs$15.23
- 10+ pcs$14.36
- 100+ pcs$13.55
- 500+ pcs$12.78
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Akım Değeri
- 15A
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Montaj
- Chassis Mount, Screw
- Pretravelmax
- 0.38 mm
- Operating Force
- 255 ~ 368gf
- Voltage Rated Ac
- 125V
- Circuit
- SPDT
- Terminal Stili
- Screw Terminal
- Çalışma Sıcaklığı
- -55°C~85°C
- Switch Function
- On-Mom
- Contact Current Rating
- 15A
- Contact Materials
- Silver
- Weight
- 3.401kg
- Operating Position
- 0.625 (15.9mm)
- Body Height
- 21.59mm
- Montaj Tipi
- Chassis Mount
- Contact Dc Max Rating R Load
- .5A@125VDC
- HTS Kodu
- 8536.50.70.00
- Release Force
- 113gf
- Terminal Kaplaması
- Matte Tin (Sn)
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Contact Currentdcmax
- 0.5A
- Differential Travel
- 0.002 (0.05mm)
- Pretravel
- 0.015 (0.4mm)
- Max Voltage Rating Dc
- 250V
- Current Rating Amps
- 15A AC 500mA DC
- Actuator Type
- Round (Pin Plunger)
- Fabrika Tedarik Süresi
- 13 Weeks
- Material
- Plastic
- Mechanical Life
- 20,000,000 Cycles
- Parça Durumu
- Active
- Terminal
- Screw
- Yayın Yılı
- 2001
- Voltage Rated Dc
- 125V
- Uzunluk
- 50.55mm
- Orientation
- Straight
- Ambalaj
- Bulk
- JESD-609 Kodu
- e3
- Housing Material
- Phenolic
- Contact Ac Max Rating R Load
- 15A@480VAC
