Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Current Rating Amps
- 5A AC 500mA DC
- Actuator Type
- Round (Pin Plunger)
- Contact Currentacmax
- 5A
- Fabrika Tedarik Süresi
- 13 Weeks
- Material
- Plastic
- Mechanical Life
- 20,000,000 Cycles
- Parça Durumu
- Active
- Terminal
- Screw
- Yayın Yılı
- 1995
- Voltage Rated Dc
- 125V
- Uzunluk
- 49.28mm
- Orientation
- Straight
- Ambalaj
- Bulk
- JESD-609 Kodu
- e3
- Housing Material
- Phenolic
- Contact Ac Max Rating R Load
- 5A@480VAC
- Overtravel
- 0.005 (0.13mm)
- Kurşunsuz Kodu
- yes
- ECCN Kodu
- EAR99
- RoHS Durumu
- RoHS Compliant
- Depth
- 17.45mm
- Actuator Travel
- 0.51 mm
- Max Current Rating
- 5A
- Seri
- BZ
- Max Voltage Rating Ac
- 480V
- Akım Değeri
- 5A
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Pretravelmax
- 0.38 mm
- Montaj
- Chassis Mount, Screw
- Operating Force
- 255 ~ 368gf
- Voltage Rated Ac
- 125V
- Circuit
- SPDT
- Terminal Stili
- Screw Terminal
- Çalışma Sıcaklığı
- -55°C~204°C
- Switch Function
- On-Mom
- Genişlik
- 49.276mm
- Contact Materials
- Silver
- Weight
- 3.401kg
- Operating Position
- 0.625 (15.9mm)
- Body Height
- 24.13mm
