Specifications
- Akım Değeri
- 10A
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Operating Force
- 184gf
- Montaj
- Chassis Mount, Panel, Screw
- Current Rating Amps
- 10A AC 500mA DC
- Actuator Type
- Lever, Roller
- Voltage Rated Ac
- 125V
- Circuit
- SPDT
- Terminal Stili
- Solder Lug
- Material
- Plastic
- Çalışma Sıcaklığı
- -55°C~85°C
- Fabrika Tedarik Süresi
- 25 Weeks
- Switch Function
- On-Mom
- Mechanical Life
- 20,000,000 Cycles
- Parça Durumu
- Active
- Terminal
- Solder
- Yayın Yılı
- 2015
- Contact Materials
- Silver
- Operating Position
- 1.188 (30.2mm)
- Actuator Material
- Stainless Steel
- Weight
- 3.401kg
- Contact Dc Max Rating R Load
- .5A@125VDC
- Uzunluk
- 49.28mm
- Voltage Rated Dc
- 125V
- Body Height
- 26.42mm
- Montaj Tipi
- Chassis Mount
- Actuator Length
- 2.442m
- HTS Kodu
- 8536.50.70.00
- Ambalaj
- Bulk
- Orientation
- Straight
- Housing Material
- Phenolic
- Release Force
- 43gf
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Contact Ac Max Rating R Load
- 10A@480VAC
- Overtravel
- 0.094 (2.4mm)
- Contact Currentdcmax
- 0.5A
- Differential Travel
- 0.145 (3.7mm)
- RoHS Durumu
- RoHS Compliant
- ECCN Kodu
- EAR99
- Kurşunsuz Kodu
- yes
