Specifications
- Max Voltage Rating Ac
- 480V
- Max Current Rating
- 15A
- Actuator Travel
- 0.64 mm
- Depth
- 17.45mm
- Seri
- BZ
- ECCN Kodu
- EAR99
- Kurşunsuz Kodu
- yes
- RoHS Durumu
- RoHS Compliant
- Contact Ac Max Rating R Load
- 15A@480VAC
- Overtravel
- 0.005 (0.13mm)
- Housing Material
- Phenolic
- Orientation
- Straight
- JESD-609 Kodu
- e3
- Ambalaj
- Bulk
- Voltage Rated Dc
- 125V
- Uzunluk
- 49.28mm
- Terminal
- Screw
- Yayın Yılı
- 2001
- Parça Durumu
- Active
- Fabrika Tedarik Süresi
- 25 Weeks
- Material
- Plastic
- Mechanical Life
- 20,000,000 Cycles
- Actuator Type
- Round (Pin Plunger)
- Current Rating Amps
- 15A AC 1A DC
- Max Voltage Rating Dc
- 250V
- Pretravel
- 0.020 (0.5mm)
- Contact Currentdcmax
- 1A
- Differential Travel
- 0.001 (0.025mm)
- Terminal Kaplaması
- Matte Tin (Sn)
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Release Force
- 113gf
- Throw Configuration
- DPDT
- HTS Kodu
- 8536.50.70.00
- Weight
- 3.401kg
- Operating Position
- 0.625 (15.9mm)
- Montaj Tipi
- Chassis Mount
- Body Height
- 26.67mm
- Contact Dc Max Rating R Load
- 1A@125VDC
- Contact Materials
- Silver
- Contact Current Rating
- 15A
