Volume pricing
- 1+ pcs$93.89
- 10+ pcs$88.58
- 100+ pcs$83.57
- 500+ pcs$78.84
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Mechanical Life
- 20,000,000 Cycles
- Akım Değeri
- 22A
- Material
- Plastic
- ECCN Kodu
- EAR99
- Contact Ac Max Rating R Load
- 22A@480VAC
- Terminal Kaplaması
- Matte Tin (Sn)
- Terminal Stili
- Screw Terminal
- RoHS Durumu
- RoHS Compliant
- Max Voltage Rating Ac
- 480V
- Max Current Rating
- 22A
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Overtravel
- 0.141 (3.6mm)
- Switch Function
- On-Mom
- Sealing
- CORROSION PROOF
- Parça Durumu
- Active
- Actuator Travel
- 3.94 mm
- Housing Material
- Phenolic
- Çalışma Sıcaklığı
- -55°C~85°C
- Orientation
- Straight
- Pretravel
- 0.015 (0.4mm)
- Release Force
- 113gf
- Depth
- 17.45mm
- Voltage Rated Ac
- 125V
- Current Rating Amps
- 22A AC
- Montaj
- Chassis Mount, Panel, Screw
- Circuit
- SPDT
- Operating Force
- 198 ~ 283gf
- JESD-609 Kodu
- e3
- HTS Kodu
- 8536.50.70.00
- Terminal
- Screw
- Pretravelmax
- 0.38 mm
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Montaj Tipi
- Chassis Mount
- Uzunluk
- 49.28mm
- Actuator Type
- Roller Plunger
- Operating Position
- 1.313 (33.4mm)
- Body Height
- 23.62mm
- Kurşunsuz Kodu
- yes
- Seri
- BM
- Yayın Yılı
- 2007
