Specifications
- Differential Travel
- 0.045 (1.1mm)
- Circuit
- SPDT
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Housing Material
- Phenolic
- Terminal
- Screw
- Akım Değeri
- 25A
- Max Voltage Rating Ac
- 480V
- Orientation
- Straight
- Operating Position
- 1.172 (29.8mm)
- Çalışma Sıcaklığı
- -55°C~85°C
- Voltage Rated Ac
- 125V
- Montaj Tipi
- Chassis Mount
- ECCN Kodu
- EAR99
- REACH Uyumluluk Kodu
- unknown
- Pretravelmax
- 6.35 mm
- Material
- Plastic
- Mechanical Life
- 20,000,000 Cycles
- Montaj
- Chassis Mount, Screw
- Pretravel
- 0.250 (6.35mm)
- Contact Materials
- Silver
- HTS Kodu
- 8536.50.70.00
- Body Height
- 30.1mm
- Kurşunsuz Kodu
- yes
- Current Rating Amps
- 25A AC
- Terminal Stili
- Screw Terminal
- Seri
- BE
- Overtravel
- 0.030 (0.76mm)
- Release Force
- 43gf
- Ambalaj
- Bulk
- Actuator Length
- 266mm
- Contact Ac Max Rating R Load
- 25A@480VAC
- Yayın Yılı
- 2001
- RoHS Durumu
- RoHS Compliant
- Actuator Travel
- 7.11 mm
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Depth
- 17.45mm
- Actuator Type
- Lever, Simulated Roller
- Weight
- 3.401kg
- Uzunluk
- 49.28mm
- Fabrika Tedarik Süresi
- 10 Weeks
