Specifications
- Parça Durumu
- Active
- Switch Function
- On-Mom
- Fabrika Tedarik Süresi
- 10 Weeks
- Operating Force
- 99gf
- Body Length Or Diameter
- 49.28mm
- Contact Current Rating
- 25A
- Weight
- 286g
- Terminal Kaplaması
- Matte Tin (Sn)
- Actuator Type
- Lever, Roller
- Depth
- 17.45mm
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- RoHS Durumu
- RoHS Compliant
- Yayın Yılı
- 2001
- Contact Ac Max Rating R Load
- 25A@480VAC
- Actuator Length
- 4.822m
- Ambalaj
- Bulk
- Release Force
- 14gf
- Overtravel
- 0.062 (1.6mm)
- Seri
- BE
- Actuator Material
- Stainless Steel
- Terminal Stili
- Screw Terminal
- Current Rating Amps
- 25A AC
- Kurşunsuz Kodu
- yes
- Body Height
- 30.1mm
- Contact Materials
- Silver
- Montaj
- Chassis Mount, Panel, Screw
- Pretravel
- 0.470 (11.9mm)
- Mechanical Life
- 20,000,000 Cycles
- Material
- Plastic
- Pretravelmax
- 11.89 mm
- ECCN Kodu
- EAR99
- Montaj Tipi
- Chassis Mount
- JESD-609 Kodu
- e3
- Voltage Rated Ac
- 125V
- Çalışma Sıcaklığı
- -55°C~85°C
- Operating Position
- 1.188 (30.2mm)
- Orientation
- Straight
- Max Voltage Rating Ac
- 480V
- Akım Değeri
- 25A
- Terminal
- Screw
