Specifications
- ECCN Kodu
- EAR99
- Mechanical Life
- 20,000,000 Cycles
- Pretravel
- 0.050 (1.27mm)
- Montaj
- Panel, Screw
- Onay Kuruluşu
- CSA, UL
- Material
- Plastic
- Kurşunsuz Kodu
- yes
- Current Rating Amps
- 25A AC
- Terminal Stili
- Screw Terminal
- Contact Materials
- Silver
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Housing Material
- Phenolic
- Pozisyon Sayısı
- 2
- Differential Travel
- 0.007 (0.18mm)
- Circuit
- SPDT
- Number Of Poles
- 1
- Terminal
- Screw
- Max Voltage Rating Ac
- 250V
- Operating Position
- 0.859 (21.8mm)
- Orientation
- Straight
- Akım Değeri
- 25A
- Montaj Tipi
- Panel Mount
- Çalışma Sıcaklığı
- -55°C~85°C
- JESD-609 Kodu
- e3
- Voltage Rated Ac
- 125V
- Actuator Type
- Overtravel Plunger
- Depth
- 17.45mm
- Terminal Kaplaması
- Matte Tin (Sn)
- Weight
- 39g
- Uzunluk
- 50.55mm
- Max Current Rating
- 25A
- Contact Current Rating
- 25A
- Parça Durumu
- Active
- Switch Function
- On-Mom
- Operating Force
- 397 ~ 624gf
- Fabrika Tedarik Süresi
- 9 Weeks
- Ambalaj
- Bulk
- Release Force
- 283gf
- Overtravel
- 0.094 (2.4mm)
- Seri
- BE
