Specifications
- Montaj
- Chassis Mount, Screw
- Body Length Or Diameter
- 101.6mm
- Pretravelmax
- 2.39 mm
- Sealing
- CORROSION PROOF
- Switch Function
- On-Mom
- Pretravel
- 0.094 (2.4mm)
- Voltage Rated Dc
- 125V
- Montaj Tipi
- Chassis Mount
- Akım Değeri
- 20A
- HTS Kodu
- 8536.50.70.00
- Voltage Rated Ac
- 125V
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Çalışma Sıcaklığı
- -32°C~71°C
- Release Force
- 340gf
- Kurşunsuz Kodu
- yes
- Operating Force
- 1134gf
- RoHS Durumu
- RoHS Compliant
- Contact Ac Max Rating R Load
- 20A@480VAC
- Actuator Type
- Roller Plunger
- Seri
- BAF1
- Fabrika Tedarik Süresi
- 4 Weeks
- Özellikler
- Actuator Mounted Left Side
- Yayın Yılı
- 2001
- Body Height
- 54.86mm
- Orientation
- Straight
- Contact Dc Max Rating R Load
- .5A@125VDC
- Terminal
- Conduit
- Housing Material
- Aluminium
- Differential Travel
- 0.010 (0.25mm)
- Parça Durumu
- Not For New Designs
- Body Breadth
- 29.46 mm
- Contact Currentdcmax
- 0.5A
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Max Current Rating
- 20A
- Max Voltage Rating Dc
- 250V
- Current Rating Amps
- 20A AC 500mA DC
- Actuator Travel
- 6.35 mm
- ECCN Kodu
- EAR99
- Terminal Stili
- Screw Terminal
- Circuit
- SPDT
