Volume pricing
- 1+ pcs$169.43
- 10+ pcs$159.84
- 100+ pcs$150.79
- 500+ pcs$142.25
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Uzunluk
- 101.6mm
- Montaj
- Chassis Mount, Screw
- Switch Function
- On-Mom
- Pozisyon Sayısı
- 2
- Montaj Tipi
- Chassis Mount
- Voltage Rated Ac
- 125V
- HTS Kodu
- 8536.50.70.00
- Akım Değeri
- 20A
- Voltage Rated Dc
- 125V
- Pretravel
- 0.094 (2.4mm)
- Release Force
- 227gf
- Kurşunsuz Kodu
- yes
- Operating Force
- 1134gf
- Çalışma Sıcaklığı
- -32°C~71°C
- RoHS Durumu
- RoHS Compliant
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Seri
- BAF1
- Actuator Type
- Round (Pin Plunger)
- Body Height
- 54.86mm
- Orientation
- Straight
- Contact Current Rating
- 20A
- Yayın Yılı
- 2001
- Özellikler
- Actuator Mounted Left Side
- Fabrika Tedarik Süresi
- 4 Weeks
- Genişlik
- 54.8mm
- Terminal
- Conduit
- Differential Travel
- 0.010 (0.25mm)
- Parça Durumu
- Not For New Designs
- Housing Material
- Aluminium
- Max Voltage Rating Dc
- 250V
- Max Current Rating
- 10A
- Contact Currentdcmax
- 0.5A
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Circuit
- SPDT
- Terminal Stili
- Screw Terminal
- ECCN Kodu
- EAR99
- Actuator Travel
- 7.95 mm
- Onay Kuruluşu
- CSA, UL
- Current Rating Amps
- 20A AC 500mA DC
- Number Of Poles
- 1
