Volume pricing
- 1+ pcs$343.99
- 10+ pcs$324.52
- 100+ pcs$306.15
- 500+ pcs$288.82
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Montaj
- Chassis Mount, Screw
- Uzunluk
- 101.6mm
- Pozisyon Sayısı
- 2
- Pretravelmax
- 5.56 mm
- Switch Function
- On-Mom
- Pretravel
- 0.219 (5.6mm)
- Voltage Rated Dc
- 125V
- Voltage Rated Ac
- 125V
- HTS Kodu
- 8536.50.70.00
- Akım Değeri
- 20A
- Montaj Tipi
- Chassis Mount
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- RoHS Durumu
- RoHS Compliant
- Kurşunsuz Kodu
- yes
- Operating Force
- 907gf
- Release Force
- 227gf
- Çalışma Sıcaklığı
- -32°C~71°C
- Seri
- BAF1
- Actuator Type
- Lever, Roller
- Yayın Yılı
- 2001
- Özellikler
- Actuator Mounted Right Side
- Fabrika Tedarik Süresi
- 4 Weeks
- Body Height
- 54.86mm
- Orientation
- Straight
- Terminal
- Conduit
- Genişlik
- 54.8mm
- Housing Material
- Aluminium
- Differential Travel
- 0.020 (0.5mm)
- Parça Durumu
- Not For New Designs
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Contact Currentdcmax
- 0.5A
- Max Voltage Rating Dc
- 250V
- Max Current Rating
- 10A
- Current Rating Amps
- 20A AC 500mA DC
- Number Of Poles
- 1
- Onay Kuruluşu
- CSA, UL
- Circuit
- SPDT
- Terminal Stili
- Screw Terminal
- ECCN Kodu
- EAR99
- Overtravel
- 0.250 (6.35mm)
