Specifications
- Current Rating Amps
- 25A AC 1A DC
- Throw Configuration
- SPDT
- Contact Materials
- Silver
- Contact Current Rating
- 20A
- Contact Currentdcmax
- 1A
- Seri
- BA
- Orientation
- Straight
- Kurşunsuz
- Lead Free
- Fabrika Tedarik Süresi
- 9 Weeks
- Çalışma Sıcaklığı
- -55°C~85°C
- Ambalaj
- Bulk
- Switch Function
- On-Mom
- Contact Dc Max Rating R Load
- 1A@125VDC
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Release Force
- 283gf
- Voltage Rated Ac
- 125V
- Mechanical Life
- 20,000,000 Cycles
- Terminal Kaplaması
- Matte Tin (Sn)
- HTS Kodu
- 8536.50.70.00
- Overtravel
- 0.010 (0.25mm)
- Montaj Tipi
- Chassis Mount
- Material
- Plastic
- Voltage Rated Dc
- 125V
- Weight
- 286g
- Body Length Or Diameter
- 49.28mm
- Body Breadth
- 17.45 mm
- Onay Kuruluşu
- CSA, UL
- Terminal
- Screw
- Operating Force
- 737 ~ 1077gf
- JESD-609 Kodu
- e3
- Yayın Yılı
- 1995
- Housing Material
- Phenolic
- RoHS Durumu
- RoHS Compliant
- Pretravelmax
- 1.65 mm
- Kurşunsuz Kodu
- yes
- Parça Durumu
- Active
- Montaj
- Chassis Mount, Screw
- ECCN Kodu
- EAR99
- Reach Svhc
- No SVHC
- Differential Travel
- 0.008 (0.2mm)
