Volume pricing
- 1+ pcs$36.31
- 10+ pcs$34.26
- 100+ pcs$32.32
- 500+ pcs$30.49
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Circuit
- SPDT
- Max Current Rating
- 20A
- Body Height
- 30.1mm
- Pretravel
- 0.630 (16.0mm)
- Depth
- 17.45mm
- Akım Değeri
- 20A
- Operating Position
- 0.750 (19.1mm)
- Contact Ac Max Rating R Load
- 20A@480VAC
- Actuator Travel
- 17.86 mm
- Actuator Type
- Lever, Straight
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Terminal Stili
- Screw Terminal
- Reach Svhc
- Unknown
- Differential Travel
- 0.110 (2.8mm)
- Kurşunsuz Kodu
- yes
- ECCN Kodu
- EAR99
- Parça Durumu
- Active
- Max Voltage Rating Ac
- 480V
- Montaj
- Chassis Mount, Screw
- Pretravelmax
- 15.88 mm
- RoHS Durumu
- RoHS Compliant
- Housing Material
- Phenolic
- Operating Force
- 71gf
- Terminal
- Screw
- Yayın Yılı
- 2001
- Max Voltage Rating Dc
- 250V
- Material
- Plastic
- Voltage Rated Dc
- 125V
- Montaj Tipi
- Chassis Mount
- Overtravel
- 0.077 (1.96mm)
- Weight
- 286g
- Body Length Or Diameter
- 49.28mm
- Voltage Rated Ac
- 125V
- HTS Kodu
- 8536.50.70.00
- Mechanical Life
- 20,000,000 Cycles
- Contact Dc Max Rating R Load
- .5A@125VDC
- Switch Function
- On-Mom
- Release Force
- 15gf
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Fabrika Tedarik Süresi
- 9 Weeks
