Specifications
- Switch Function
- On-Mom
- Contact Dc Max Rating R Load
- .5A@125VDC
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Release Force
- 15gf
- Voltage Rated Ac
- 125V
- Mechanical Life
- 20,000,000 Cycles
- Terminal Kaplaması
- Matte Tin (Sn)
- HTS Kodu
- 8536.50.70.00
- Overtravel
- 0.077 (1.96mm)
- Material
- Plastic
- Voltage Rated Dc
- 125V
- Montaj Tipi
- Chassis Mount
- Weight
- 286g
- Body Length Or Diameter
- 49.28mm
- Contact Materials
- Silver
- Current Rating Amps
- 20A AC 500mA DC
- Contact Current Rating
- 20A
- Contact Currentdcmax
- 0.5A
- Seri
- BA
- Orientation
- Straight
- Actuator Length
- 635mm
- Fabrika Tedarik Süresi
- 9 Weeks
- Çalışma Sıcaklığı
- -55°C~85°C
- Ambalaj
- Bulk
- Operating Position
- 0.750 (19.1mm)
- Terminal Stili
- Solder Lug
- Actuator Travel
- 17.86 mm
- Contact Ac Max Rating R Load
- 20A@480VAC
- Actuator Type
- Lever, Straight
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Akım Değeri
- 20A
- Body Height
- 27.31mm
- Depth
- 17.45mm
- Pretravel
- 0.630 (16.0mm)
- Max Current Rating
- 20A
- Circuit
- SPDT
- Terminal
- Solder
- Operating Force
- 71gf
- Max Voltage Rating Dc
- 250V
- JESD-609 Kodu
- e3
