Specifications
- Kurşunsuz Kodu
- yes
- Orientation
- Straight
- ECCN Kodu
- EAR99
- Parça Durumu
- Active
- Max Voltage Rating Ac
- 480V
- Montaj
- Chassis Mount, Screw
- Fabrika Tedarik Süresi
- 9 Weeks
- Çalışma Sıcaklığı
- -55°C~85°C
- Reach Svhc
- Unknown
- Ambalaj
- Bulk
- Differential Travel
- 0.002 (0.05mm)
- Operating Force
- 397 ~ 624gf
- Contact Materials
- Silver
- Terminal
- Screw
- Current Rating Amps
- 20A AC 500mA DC
- Yayın Yılı
- 2001
- Max Voltage Rating Dc
- 250V
- Contact Currentdcmax
- 0.5A
- Pretravelmax
- 1.27 mm
- RoHS Durumu
- RoHS Compliant
- Housing Material
- Phenolic
- Seri
- BA
- Body Height
- 21.59mm
- Uzunluk
- 50.55mm
- Pretravel
- 0.050 (1.27mm)
- Depth
- 17.45mm
- Voltage Rated Dc
- 125V
- Material
- Plastic
- Montaj Tipi
- Chassis Mount
- Overtravel
- 0.010 (0.25mm)
- Circuit
- SPDT
- Weight
- 286g
- Max Current Rating
- 20A
- Contact Dc Max Rating R Load
- .5A@125VDC
- Operating Position
- 0.640 (16.3mm)
- Switch Function
- On-Mom
- Actuator Type
- Round (Pin Plunger)
- Contact Ac Max Rating R Load
- 20A@480VAC
- Actuator Travel
- 1.52 mm
- Release Force
- 283gf
