Specifications
- Depth
- 16.2mm
- Pretravel
- 0.063 (1.6mm)
- Actuator Type
- Cross Roller Plunger
- Insulation Resistance
- 100MOhm
- Yayın Yılı
- 2007
- Terminal
- Cable Leads
- Ambalaj
- Bulk
- Contact Resistance
- 25mOhm
- Reach Svhc
- Unknown
- Differential Travel
- 0.055 (1.4mm)
- Current Rating Amps
- 6A AC 550mA DC
- Lead Length
- 1m
- Circuit
- DPST-NO/NC
- Switch Function
- On-Mom, Off-Mom
- Parça Durumu
- Obsolete
- Operating Force
- 816gf
- Throw Configuration
- DPST, SPDT
- Voltage Rated Dc
- 125V
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Ratings
- Dust Tight, IP67, Waterproof
- Max Voltage Rating Ac
- 300V
- Onay Kuruluşu
- CCC, CE, cULus
- Electricallife
- 500,000 Cycles
- Yükseklik
- 70.3mm
- Montaj
- Chassis Mount, Screw
- Genişlik
- 30mm
- Voltage Rated Ac
- 120V
- Overtravel
- 0.134 (3.4mm)
- Özellikler
- Cable Length 1m
- Ingress Protection
- IP67 - Dust Tight, Waterproof
- Uzunluk
- 30mm
- Fabrika Tedarik Süresi
- 6 Weeks
- Mechanical Life
- 5,000,000 Cycles
- Terminal Stili
- Cable Leads
- Max Voltage Rating Dc
- 250V
- Seri
- 91MCE
- Akım Değeri
- 6A
- Kılıf / Paket
- 300
- Orientation
- Straight
- RoHS Durumu
- RoHS Compliant
