Volume pricing
- 1+ pcs$153.72
- 10+ pcs$145.02
- 100+ pcs$136.81
- 500+ pcs$129.07
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Ingress Protection
- Waterproof
- Fabrika Tedarik Süresi
- 23 Weeks
- Uzunluk
- 22.25mm
- Overtravel
- 0.003 (0.076mm)
- Release Force
- 57gf
- REACH Uyumluluk Kodu
- unknown
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Contact Currentdcmax
- 5A
- Operating Force
- 113 ~ 227gf
- HTS Kodu
- 8536.50.70.00
- Montaj
- Panel, Screw, Wire
- Terminal Stili
- Wire Leads
- Max Current Rating
- 5A
- ECCN Kodu
- EAR99
- Sealing
- CORROSION PROOF
- Contact Ac Max Rating R Load
- 5A@250VAC
- Pretravel
- 0.050 (1.27mm)
- Differential Travel
- 0.004 (0.1mm)
- Çalışma Sıcaklığı
- -54°C~105°C
- Voltage Rated Ac
- 250V
- Contact Materials
- Silver
- Orientation
- Straight
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Max Voltage Rating Dc
- 28V
- Current Rating Amps
- 5A AC/DC
- Montaj Tipi
- Chassis Mount
- Switch Function
- On-Mom
- Max Voltage Rating Ac
- 250V
- Voltage Rated Dc
- 30V
- Parça Durumu
- Active
- Circuit
- SPDT
- Operating Position
- 0.425 (10.8mm)
- Actuator Type
- Round (Pin Plunger)
- Depth
- 8.79mm
- RoHS Durumu
- RoHS Compliant
- Pretravelmax
- 1.27 mm
- Contact Dc Max Rating R Load
- 5A@250VDC
- Terminal
- Wire Leads
- Body Height
- 15.24mm
- Actuator Material
- Steel
