Request a quote for pricing
Priced by quantity and lead time.
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Max Current Rating
- 10A
- Ambalaj
- Bulk
- Throw Configuration
- SPDT
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Kurşunsuz Kodu
- yes
- Switch Function
- On-On
- Body Breadth
- 39.878 mm
- Montaj Tipi
- Chassis Mount
- HTS Kodu
- 8536.50.70.00
- Max Voltage Rating Dc
- 550V
- Fabrika Tedarik Süresi
- 20 Weeks
- Özellikler
- Nylon Roller
- Housing Material
- Zinc
- Contact Ac Max Rating R Load
- 10A@480VAC
- Voltage Rated Dc
- 115V
- RoHS Durumu
- RoHS Compliant
- Ingress Protection
- IP67 - Dust Tight, Waterproof
- Ratings
- Dust Tight, IP67, Waterproof
- Circuit
- SPDT (DB/DM)
- Çalışma Sıcaklığı
- -29°C~71°C
- Akım Değeri
- 10A
- Voltage Rated Ac
- 120V
- Seri
- LS
- Montaj
- Chassis Mount, Screw
- Body Height
- 40.64mm
- Terminal
- Conduit
- Contact Voltageacmax
- 480V
- Parça Durumu
- Active
- Actuator Type
- Side Rotary, Fork Lever Lock (Yoke)
- ECCN Kodu
- EAR99
- Terminal Stili
- Screw Terminal
- Current Rating Amps
- 10A AC 800mA DC
- Operating Force
- 34gfm
- Pretravel
- 55°
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Body Length Or Diameter
- 68.58mm
- Contact Currentdcmax
- 0.8A
