Volume pricing
- 1+ pcs$29.55
- 10+ pcs$27.88
- 100+ pcs$26.30
- 500+ pcs$24.81
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Max Voltage Rating Dc
- 28V
- Operating Position
- 0.320 (8.13mm)
- Yayın Yılı
- 1995
- Circuit
- SPDT
- Kurşunsuz Kodu
- yes
- Parça Durumu
- Active
- Release Force
- 28gf
- Weight
- 136g
- ECCN Kodu
- EAR99
- Depth
- 5.08mm
- Contact Materials
- Silver
- Current Rating Amps
- 7A AC/DC
- Max Current Rating
- 7A
- Voltage Rated Ac
- 250V
- Differential Travel
- 0.005 (0.13mm)
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Çalışma Sıcaklığı
- -55°C~204°C
- Operating Force
- 141gf
- Contact Ac Max Rating R Load
- 7A@250VAC
- Contact Currentacmax
- 7A
- Montaj
- Chassis Mount, Panel, Screw, Solder
- Voltage Rated Dc
- 28V
- Max Voltage Rating Ac
- 250V
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Fabrika Tedarik Süresi
- 12 Weeks
- Actuator Material
- Plastic
- Ambalaj
- Bulk
- Body Height
- 8.89mm
- Switch Function
- On-Mom
- Housing Material
- Phenolic
- HTS Kodu
- 8536.50.70.00
- Seri
- SX
- Terminal Stili
- Quick Connect - 0.058 (Round)
- Uzunluk
- 12.7mm
- Contact Dc Max Rating R Load
- 7A@28VDC
- Akım Değeri
- 7A
- Montaj Tipi
- Chassis Mount
- Pretravelmax
- 0.51 mm
- Orientation
- Straight
- Mechanical Life
- 1,000,000 Cycles
