Volume pricing
- 1+ pcs$8.60
- 10+ pcs$8.12
- 100+ pcs$7.66
- 500+ pcs$7.22
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Weight
- 136g
- Overtravel
- 0.004 (0.1mm)
- Orientation
- Straight
- Current Rating Amps
- 2A DC
- Switch Function
- On-Mom
- Yayın Yılı
- 1995
- Pretravelmax
- 0.51 mm
- Operating Force
- 141gf
- Uzunluk
- 12.7mm
- Voltage Rated Dc
- 28V
- Kurşunsuz Kodu
- yes
- Actuator Material
- Plastic
- Akım Değeri
- 2A
- Ambalaj
- Bulk
- Contact Current Rating
- 2A
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Actuator Type
- Round (Pin Plunger)
- Differential Travel
- 0.002 (0.05mm)
- ECCN Kodu
- EAR99
- Terminal Stili
- Solder Turret
- Pretravel
- 0.020 (0.5mm)
- HTS Kodu
- 8536.50.70.00
- Fabrika Tedarik Süresi
- 11 Weeks
- Circuit
- SPDT
- Housing Material
- Phenolic
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Depth
- 5.08mm
- Montaj Tipi
- Chassis Mount
- Mechanical Life
- 10,000,000 Cycles
- Seri
- SX
- Release Force
- 28gf
- Contact Materials
- Gold, Silver
- Operating Position
- 0.320 (8.13mm)
- RoHS Durumu
- RoHS Compliant
- Çalışma Sıcaklığı
- -53°C~204°C
- Yükseklik
- 13.21mm
- Terminal
- Solder
- Montaj
- Chassis Mount, Panel, Screw, Solder
- Parça Durumu
- Active
