Specifications
- Circuit
- SPDT
- Yayın Yılı
- 1995
- Switch Function
- On-Mom
- Montaj Tipi
- Chassis Mount
- Current Rating Amps
- 1A AC/DC
- Contact Materials
- Gold, Silver
- Housing Material
- Phenolic
- Voltage Rated Dc
- 30V
- Contact Currentacmax
- 1A
- Kılıf / Paket
- 125
- ECCN Kodu
- EAR99
- HTS Kodu
- 8536.50.70.00
- Akım Değeri
- 1A
- Depth
- 5.08mm
- Uzunluk
- 12.7mm
- Mechanical Life
- 1,000,000 Cycles
- Contact Current Rating
- 1A
- Terminal
- Solder
- Actuator Type
- Round (Pin Plunger)
- Max Voltage Rating Ac
- 250V
- Kurşunsuz Kodu
- yes
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Pretravel
- 0.020 (0.5mm)
- Number Of Poles
- 1
- Çalışma Sıcaklığı
- -55°C~125°C
- Contact Currentdcmax
- 1A
- Max Voltage Rating Dc
- 30V
- Fabrika Tedarik Süresi
- 6 Weeks
- RoHS Durumu
- RoHS Compliant
- Seri
- SX
- Body Height
- 8.89mm
- Weight
- 136g
- Release Force
- 28gf
- Contact Plating
- Gold
- Terminal Stili
- Solder Turret
- Reach Svhc
- Unknown
- Operating Force
- 141gf
- Orientation
- Straight
- Differential Travel
- 0.005 (0.12mm)
- Overtravel
- 0.004 (0.1mm)
