Volume pricing
- 1+ pcs$16.08
- 10+ pcs$15.17
- 100+ pcs$14.31
- 500+ pcs$13.50
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Contact Currentdcmax
- 1A
- Mechanical Life
- 10,000,000 Cycles
- Operating Force
- 68gf
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Release Force
- 11gf
- Parça Durumu
- Active
- Contact Currentacmax
- 1A
- Yayın Yılı
- 1995
- Housing Material
- Phenolic
- Montaj Tipi
- Chassis Mount
- Depth
- 5.08mm
- ECCN Kodu
- EAR99
- Switch Function
- On-Mom
- Operating Position
- 0.557 (14.15mm)
- Body Height
- 8.89mm
- Pretravelmax
- 1.27 mm
- Differential Travel
- 0.015 (0.38mm)
- Circuit
- SPDT
- Reach Svhc
- Unknown
- Actuator Material
- Stainless Steel
- Overtravel
- 0.010 (0.25mm)
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Voltage Rated Dc
- 30V
- Max Current Rating
- 1A
- Contact Current Rating
- 1A
- Ambalaj
- Bulk
- Montaj
- Chassis Mount, Screw, Solder
- Weight
- 136g
- Contact Ac Max Rating R Load
- 1A@125VAC
- Orientation
- Straight
- Contact Dc Max Rating R Load
- 1A@30VDC
- Voltage Rated Ac
- 125V
- RoHS Durumu
- RoHS Compliant
- Çalışma Sıcaklığı
- -55°C~125°C
- Sealing
- CORROSION PROOF
- Kurşunsuz Kodu
- yes
- HTS Kodu
- 8536.50.70.00
- Terminal
- Solder
- Actuator Length
- 11mm
- Pretravel
- 0.050 (1.27mm)
