Volume pricing
- 1+ pcs$37.76
- 10+ pcs$35.62
- 100+ pcs$33.61
- 500+ pcs$31.70
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Depth
- 5.1mm
- Çalışma Sıcaklığı
- -55°C~125°C
- Montaj Tipi
- Chassis Mount
- Housing Material
- Phenolic
- Parça Durumu
- Active
- Voltage Rated Ac
- 125V
- Contact Currentacmax
- 1A
- RoHS Durumu
- RoHS Compliant
- Yayın Yılı
- 1995
- Release Force
- 5.099gf
- Orientation
- Straight
- Contact Current Rating
- 1A
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Weight
- 136g
- Ambalaj
- Bulk
- Montaj
- Chassis Mount, Screw, Solder
- Max Current Rating
- 1A
- Operating Force
- 30gf
- Mechanical Life
- 10,000,000 Cycles
- Voltage Rated Dc
- 30V
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Body Breadth
- 5.08 mm
- Onay Kuruluşu
- CSA, UL
- Contact Currentdcmax
- 1A
- Contact Plating
- Gold
- Uzunluk
- 23.75mm
- Overtravel
- 0.025 (0.6mm)
- Akım Değeri
- 1A
- Actuator Type
- Lever, Straight
- Seri
- SX
- Differential Travel
- 0.035 (0.9mm)
- Current Rating Amps
- 1A AC/DC
- Circuit
- SPDT
- Fabrika Tedarik Süresi
- 4 Weeks
- Contact Materials
- Gold, Silver
- Pozisyon Sayısı
- 2
- Pretravel
- 0.114 (2.9mm)
- Switch Function
- On-Mom
- Operating Position
- 0.325 (8.25mm)
- Terminal Stili
- Solder Turret
