Specifications
- Pozisyon Sayısı
- 2
- Ambalaj
- Tray
- Kurşunsuz
- Lead Free
- HTS Kodu
- 8536.50.70.00
- Voltage Rated Ac
- 250V
- Max Current Rating
- 5A
- ECCN Kodu
- EAR99
- Overtravel
- 0.022 (0.55mm)
- Differential Travel
- 0.035 (0.9mm)
- Voltage Rated Dc
- 28V
- Contact Currentacmax
- 5A
- Orientation
- Straight
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Body Breadth
- 5.08 mm
- Kurşunsuz Kodu
- yes
- Actuator Type
- Lever, Simulated Roller
- Terminal
- Solder
- Montaj
- Chassis Mount, Screw, Solder
- Operating Position
- 0.585 (14.86mm)
- Contact Current Rating
- 5A
- Uzunluk
- 24.95mm
- Depth
- 5.1mm
- Mechanical Life
- 10,000,000 Cycles
- Parça Durumu
- Active
- Akım Değeri
- 5A
- Release Force
- 5.099gf
- Actuator Length
- 117mm
- Weight
- 136g
- Circuit
- SPDT
- Seri
- SX
- RoHS Durumu
- RoHS Compliant
- Fabrika Tedarik Süresi
- 6 Weeks
- Contact Currentdcmax
- 5A
- Çalışma Sıcaklığı
- -55°C~125°C
- Pretravel
- 0.106 (2.7mm)
- Number Of Poles
- 1
- Onay Kuruluşu
- CSA, UL
- Housing Material
- Phenolic
- Operating Force
- 30gf
