Volume pricing
- 1+ pcs$17.92
- 10+ pcs$16.91
- 100+ pcs$15.95
- 500+ pcs$15.05
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Çalışma Sıcaklığı
- -55°C~125°C
- Number Of Poles
- 1
- Pretravel
- 0.050 (1.27mm)
- Seri
- SX
- RoHS Durumu
- RoHS Compliant
- Contact Currentdcmax
- 5A
- Fabrika Tedarik Süresi
- 6 Weeks
- Release Force
- 11gf
- Actuator Length
- 11mm
- Weight
- 136g
- Reach Svhc
- Unknown
- Terminal Stili
- Solder Turret
- Yükseklik
- 18.75mm
- Operating Force
- 60gf
- Overtravel
- 0.010 (0.25mm)
- Orientation
- Straight
- Differential Travel
- 0.015 (0.38mm)
- Max Current Rating
- 5A
- Kurşunsuz
- Lead Free
- Voltage Rated Ac
- 250V
- Ambalaj
- Tray
- Pozisyon Sayısı
- 2
- Parça Durumu
- Active
- Montaj
- Chassis Mount, Screw, Solder
- Operating Position
- 0.557 (14.15mm)
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Onay Kuruluşu
- CSA, UL
- Circuit
- SPDT
- Montaj Tipi
- Chassis Mount
- Switch Function
- On-Mom
- Current Rating Amps
- 5A AC/DC
- Yayın Yılı
- 1995
- Housing Material
- Phenolic
- Contact Materials
- Gold, Silver
- Voltage Rated Dc
- 28V
- Contact Currentacmax
- 5A
- ECCN Kodu
- EAR99
- HTS Kodu
- 8536.50.70.00
- Mechanical Life
- 10,000,000 Cycles
- Uzunluk
- 14.7mm
