Specifications
- Max Current Rating
- 5A
- Overtravel
- 0.025 (0.6mm)
- Orientation
- Straight
- Differential Travel
- 0.060 (1.5mm)
- Pozisyon Sayısı
- 2
- Ambalaj
- Tray
- Kurşunsuz
- Lead Free
- Voltage Rated Ac
- 250V
- Montaj
- Chassis Mount, Screw, Solder
- Operating Position
- 0.305 (7.75mm)
- Terminal Kaplaması
- Gold (Au)
- Pretravelmax
- 4.7 mm
- Parça Durumu
- Active
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Çalışma Sıcaklığı
- -55°C~125°C
- Pretravel
- 0.185 (4.7mm)
- Number Of Poles
- 1
- Actuator Length
- 245mm
- Release Force
- 3.059gf
- Weight
- 136g
- Seri
- SX
- RoHS Durumu
- RoHS Compliant
- Contact Currentdcmax
- 5A
- Fabrika Tedarik Süresi
- 9 Weeks
- Yükseklik
- 13.6mm
- Reach Svhc
- Unknown
- Terminal Stili
- Solder Turret
- JESD-609 Kodu
- e4
- Operating Force
- 20gf
- ECCN Kodu
- EAR99
- Contact Currentacmax
- 5A
- Voltage Rated Dc
- 28V
- HTS Kodu
- 8536.50.70.00
- Contact Current Rating
- 5A
- Depth
- 5.1mm
- Uzunluk
- 35.35mm
- Mechanical Life
- 10,000,000 Cycles
- Akım Değeri
- 5A
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Kurşunsuz Kodu
- yes
