Volume pricing
- 1+ pcs$19.20
- 10+ pcs$18.12
- 100+ pcs$17.09
- 500+ pcs$16.12
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Pretravel
- 0.120 (3.0mm)
- Çalışma Sıcaklığı
- -55°C~125°C
- Fabrika Tedarik Süresi
- 10 Weeks
- Contact Currentdcmax
- 5A
- Circuit
- SPDT
- Actuator Travel
- 3.71 mm
- RoHS Durumu
- RoHS Compliant
- Seri
- SM
- Weight
- 272g
- Body Height
- 9.04mm
- Genişlik
- 19.8mm
- Actuator Length
- 1.359m
- Release Force
- 2.039gfm
- Terminal Stili
- Solder Turret
- Yayın Yılı
- 1995
- Current Rating Amps
- 4A AC 5A DC
- Reach Svhc
- No SVHC
- Montaj Tipi
- Chassis Mount
- Switch Function
- On-Mom
- Contact Materials
- Silver
- Operating Force
- 12gf
- Housing Material
- Phenolic
- Contact Ac Max Rating R Load
- 10A@250VAC
- Differential Travel
- 0.015 (0.38mm)
- Voltage Rated Dc
- 30V
- Orientation
- Straight
- Contact Currentacmax
- 10A
- Overtravel
- 0.026 (0.7mm)
- ECCN Kodu
- EAR99
- Max Current Rating
- 4A
- HTS Kodu
- 8536.50.70.00
- Voltage Rated Ac
- 250V
- Ambalaj
- Bulk
- Parça Durumu
- Active
- Akım Değeri
- 5A
- Pretravelmax
- 3.05 mm
- Mechanical Life
- 10,000,000 Cycles
- Depth
- 6.4mm
- Uzunluk
- 31.25mm
- Operating Position
- 0.455 (11.6mm)
