Specifications
- Kurşunsuz Kodu
- yes
- Body Breadth
- 6.35 mm
- Contact Timing
- SNAP ACTION
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Actuator Type
- Lever, Simulated Roller
- Terminal
- Solder
- Contact Current Rating
- 5A
- Akım Değeri
- 5A
- Mechanical Life
- 10,000,000 Cycles
- Uzunluk
- 24.05mm
- Depth
- 6.4mm
- HTS Kodu
- 8536.50.70.00
- ECCN Kodu
- EAR99
- Contact Currentacmax
- 5A
- Voltage Rated Dc
- 30V
- Contact Materials
- Gold, Silver
- Housing Material
- Phenolic
- Yayın Yılı
- 1995
- Current Rating Amps
- 5A AC/DC
- Montaj Tipi
- Chassis Mount
- Switch Function
- On-Mom
- Circuit
- SPDT
- Onay Kuruluşu
- CSA, UL
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Operating Position
- 0.460 (11.7mm)
- Montaj
- Chassis Mount, Screw, Solder
- Parça Durumu
- Active
- Ambalaj
- Tray
- Pozisyon Sayısı
- 2
- Voltage Rated Ac
- 250V
- Kurşunsuz
- Lead Free
- Max Current Rating
- 5A
- Differential Travel
- 0.020 (0.5mm)
- Orientation
- Straight
- Overtravel
- 0.018 (0.45mm)
- Operating Force
- 40gf
- Yükseklik
- 14.5mm
- Terminal Stili
- Solder Turret
- Reach Svhc
- Unknown
- Weight
- 272g
