Volume pricing
- 1+ pcs$66.81
- 10+ pcs$63.03
- 100+ pcs$59.46
- 500+ pcs$56.10
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Voltage Rated Ac
- 125V
- Contact Materials
- Cadmium, Silver
- REACH Uyumluluk Kodu
- unknown
- Contact Plating
- Cadmium, Silver
- Montaj Tipi
- Panel Mount
- Ratings
- Environment Proof
- RoHS Durumu
- RoHS Compliant
- Sealing
- DUST PROOF; WATER PROOF
- HTS Kodu
- 8536.50.90.65
- Max Voltage Rating Ac
- 277V
- Ingress Protection
- Environment Sealed
- Contact Currentdcmax
- 20A
- Switch Function
- On-Off-On
- Terminal Stili
- Screw Terminal
- Actuator Length
- 26.67mm
- Terminal
- Screw
- Actuator Type
- Locking Lever
- Actuator Material
- Nickel Plated
- Circuit
- DPDT
- Montaj
- Bushing
- Çalışma Sıcaklığı
- -65°C~71°C
- Panel Cutout Dimensions
- Circular - 12.40mm Dia
- Illumination Type
- Illuminated, Non-Illuminated
- Current Rating Amps
- 15A AC
- Parça Durumu
- Active
- Kurşunsuz Kodu
- yes
- Fabrika Tedarik Süresi
- 26 Weeks
- Max Voltage Rating Dc
- 250V
- Orientation
- Straight
- Contact Ac Max Rating R Load
- 15A@125VAC
- Switch Type
- TOGGLE SWITCH
- Voltage Rated Dc
- 250V
- Illumination
- Non-Illuminated
- Body Height
- 34.29mm
- ECCN Kodu
- EAR99
- Bushing Thread
- 15/32-32
- Seri
- TL
- Body Length Or Diameter
- 34.04mm
- Contact Dc Max Rating R Load
- 20A@28VDC
- Yayın Yılı
- 2009
