Specifications
- Yayın Yılı
- 1999
- Terminal Stili
- Wire Leads
- Current Rating Amps
- 4A AC/DC
- Reach Svhc
- Unknown
- Switch Function
- On-Mom
- Montaj Tipi
- Chassis Mount
- Operating Force
- 198gf
- Contact Dc Max Rating R Load
- 4A@28VDC
- Contact Ac Max Rating R Load
- 2A@115VAC
- Pretravel
- 0.030 (0.8mm)
- Çalışma Sıcaklığı
- -65°C~121°C
- Max Voltage Rating Dc
- 28V
- Fabrika Tedarik Süresi
- 7 Weeks
- Contact Currentdcmax
- 4A
- Actuator Travel
- 0.84 mm
- Circuit
- SPDT
- Seri
- HM
- RoHS Durumu
- RoHS Compliant
- Weight
- 28.35g
- Body Height
- 17.02mm
- Release Force
- 28gf
- Parça Durumu
- Active
- Akım Değeri
- 4A
- Pretravelmax
- 0.76 mm
- Uzunluk
- 20.04mm
- Depth
- 6.35mm
- Operating Position
- 0.330 (8.4mm)
- Contact Current Rating
- 4A
- Montaj
- Screw, Wire
- Actuator Type
- Lever, Straight
- Terminal
- Wire
- Max Voltage Rating Ac
- 115V
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Differential Travel
- 0.006 (0.15mm)
- Voltage Rated Dc
- 28V
- Contact Currentacmax
- 2A
- Orientation
- Straight
- Overtravel
- 0.003 (0.076mm)
- ECCN Kodu
- EAR99
